Temperature Indicators
Temperature Indicators
Electronic Oil Temperature
2 1/4" Air Core (270° Sweep)
(Optional Opti-Alert system shown)
Opti-Alert warning system available
Weight 2 1/4″ Air Core: 4.7 Oz. Case: Valox 420 Plastic
Weight 2 1/4″ Pivot & Jewel: 5.8 Oz. Case: Valox 420 Plastic
| Part # | Range | Dial Marking | Probe |
|---|---|---|---|
| 12-260-300 | 100 to 300° F | B&W | 1BX |
| 12-260-150C | 40 to 150° C | B&W | 1BX |
2 1/4" Electronic Case
2 1/4" Electronic Case (Pivot & Jewel)
1 1/4" Air Core (270° Sweep
Weight 1 1/4″ Air Core: 4.0 Oz. Case: Aluminum
| Part # | Range | Dial Markings | Probe |
|---|---|---|---|
| N12-113U-150C-000 | 100 to 150° C | B&W | 1BX |
| N12-113U-300F-000 | 100 to 300° F | B&W | 1BX |
| N12-113V-300F-000 | 100 to 300° F | B&W | Uses Existing VDO Probe (Rotax 912/914) |
1 1/4" Electronic Gauge Mounting
Electronic Water Temperature
2 1/4" Water Temperature (Air Core)
(Optional Opti-Alert system shown)
Opti-Alert warning system available
Weight: 4.7 Oz. Case: Valox 420 Plastic
| Part # | Range | Dial Marking | Sender(Sold Separately) |
|---|---|---|---|
| 12-360-300 | 100-300° F | B&W | 1BX Type |
| 12-360-150C | 40-50° C | B&W | 1BX Type |
MOUNTING INFORMATION
1 1/4" Water Temperature (Air Core)
Weight: 4.0 Oz. Case: Aluminum
| Part # | Range | Dial Marking | Sender(Sold Separately) |
|---|---|---|---|
| N12-115U-150C-000 | 40-150° C | B&W | 1BX Type |
| N12-115U-300F-000 | 100-300° F | B&W | 1BX Type |
| N12-115V-300F-000 | 100-300° F | B&W | VDO |
MOUNTING INFORMATION
Cylinder Head Temperature
2 1/4″ self-powered
CHT gauge (non TSO only)
2 1/4″ Air Core
(Optional Opti-Alert system shown)
Available with TSO
1 1/4″ Air Core
Available with TSO
2 1/4" Air Core (270° Sweep)
Weight 2 1/4″ Air Core: 4.7 Oz. Case: Valox 420 Plastic
Weight 2 1/4″ Pivot & Jewel: 5.8 Oz. Case: Valox 420 Plastic
| Part # | Range | Dial Marking | Probe |
|---|---|---|---|
| 12-460-300 | 100 to 300°F | B&W | 1BX |
| 12-460-150C | 40 to 150°C | B&W | 1BX |
| 12-460-600 | 100 to 600°F | B&W | 2BX (Type J Thermocouple) |
| 12-450-600 | 100 to 600°F | B&W | Type J Thermocouple (self-powered) |
1 1/4" Air Core (270° Sweep)
Weight: 4.0 Oz. Case: Aluminum
| Part # | Range | Dial Markings | Probe |
|---|---|---|---|
| N12-116U-150C-000 | 100 to 300°F | B&W | 1BX |
| N12-116U-300F-000 | 40 to 150°C | B&W | 1BX |
| N12-116J-600F-000 | 100 to 600°F | B&W | 2BX (Type J Thermocouple) |
2 1/4" Electronic Case
2 1/4" Electronic Case (Pivot & Jewel)
1 1/4" Electronic Gauge Mounting
Carburetor Air Temperature
2 1/4" Carb. Temp gauge with °C dial, T3Bx "K" thermocouple probe(TSO) Available with TSO
Requires T3BX UMA Thermocouple Temperature Probe or equivalent
| Part # | Range | Dial Marking |
|---|---|---|
| N12-218K-060C-000 | (-40) to (+60) °C | B&W |
2 1/4" Carb. Temp gauge with °C dial, 1Bx UMA thermistor probe (non TSO) Gauge Available with TSO
Requires 1Bx UMA Thermistor Temperature Probe or equivalent
| Part # | Range | Dial Marking |
|---|---|---|
| N12-218U-050C-000 | (-50) to (+50) °C | B&W |
2 1/4" Carburetor Air Temperature
(Optional Opti-Alert and dial markings shown)
Available with TSO
Requires 1B8 Temp Probe or equivalent.
Weight 2 1/4″: 4.7 Oz.
| Part # | Range | Dial Marking |
|---|---|---|
| 12-630-120F | (-60) to 120°F | B&W |
1 1/4" Carburetor Air Temperature
Available with TSO
Requires 1B8 Temp Probe or equivalent
Weight 1 1/4″: 1.4 Oz.
| Part # | Range | Dial Marking |
|---|---|---|
| N12-118U-120F-000 | (-60) to 120°F | B&W |
Exhaust Gas Temperature
2 1/4" Air Core (270° Sweep)
(Optional Opti-Alert system shown)
Available with TSO
| Part # | Range | Dial Marking | Probe |
|---|---|---|---|
| 12-560-1K7 | 700 to 1700° F | B&W | 2BXX (Type K Thermocouple) |
| 12-60-900C | 400 to 900° C | B&W | 2BXX (Type K Thermocouple) |
Weight 2 1/4″ Air Core: 4.7 Oz. Case: Valox 420 Plastic
2 1/4" Pivot & Jewel (90° Sweep)
No power required!
| Part # | Range | Dial Marking | Probe |
|---|---|---|---|
| 12-500-10 | 700 to 1700° F | B&W | 2BXX (Type K Thermocouple) |
Weight 2 1/4″ Pivot & Jewel: 5.8 Oz. Case: Valox 420 Plastic
1 1/4" Air Core (270° Sweep)
Available with TSO
| Part # | Range | Dial Markings | Probe |
|---|---|---|---|
| N12-117K-1K7F-000 | 700 to 1700° F | B&W | 2BXX (Type K Thermocouple) |
| N12-117K-19CC-000 | 400 to 900° C | B&W | 2BXX (Type K Thermocouple) |
Weight 1 1/4″ Air Core: 4.0 Oz. Case: Aluminum
